IMOCA 60 | |
The JL60 is an IMOCA class racing monohull, designed for speed, offshore racing, single-handed, double-handed or even with a small crew, to participate to "The Ocean Race". This one has been designed to participate in all the races of the IMOCA schedule, but the most important one is the Vendée Globe. One more design in the family of the Imocas on SA3, templates avaliable on discord for the liveries. Lots of interactive parts (jokey poles at the back need to be clicked at their base to be activated). Lines are in FRENCH, if you want to translate them, I can provide you a translation file, then you can modifiy them as you wish by clicking the small winch under the design, then lines, as the deck layout modification is enabled. Updates to come soon... PM me for any remarks, questions etc... Enjoy ! |
|
created by jl_lr performance weight 38.98005 |
|
Specifications: |
|
Class | Imoca |
Hull type | Monohull with foils |
Length over all | 20.12 m. / 66.0 ft. |
Length waterline | 14.78 m. / 48.5 ft. |
Beam | 15.60 m. / 51.2 ft. |
Depth | 4.42 m. / 14.5 ft. |
Minimum depth | 3.52 m. / 11.5 ft. |
Total weight | 8500 kg / 8.4 long tonnes |
Ballast | 2850 kg / 6283 pounds |
Max. waterballast per side | 800 liter |
Mast | 28.82 m. / 94.5 ft. |
Sail area up wind | 284.6 m². / 3064 ft². |
Max. sail area | 466.2 m². / 5018 ft². |
D/L ratio | 66 |
S/D ratio | 68.3 |
Sails: | |
Mainsail | 148.0 m². / 1593 ft². laminate 3 reefs |
Gennaker | 318.2 m². / 3425 ft². laminate |
Genoa | 136.6 m². / 1470 ft². laminate |
Code 0 | 250.1 m². / 2692 ft². laminate |
Nr 1 | 208.0 m². / 2238 ft². laminate |
Nr 3 | 93.4 m². / 1005 ft². laminate |
Nr 4 | 51.0 m². / 549 ft². laminate |
Stormjib | 22.7 m². / 244 ft². dacron |
